LED3000 Series Continuous Fixing and Drying Machine | Compact Finishing Unit for Narrow Woven Strips
Energy-Efficient Hot Air Drying System for Elastic and Non-Elastic Narrow Webs
The Ledmak LED3000 Series is a modular machine series developed to offer high efficiency and energy savings in the continuous fixing, drying, and pigment dyeing processes of elastic and non-elastic narrow woven webs.
- Compact design: Minimal space requirement, easy maintenance access
- Energy-efficient hot air dryer: More efficient than cylindrical systems
- Modular design: Customizable configuration based on requirements
- Parallel strip alignment: Prevents slippage, ensures even results
- Optional pre-dryer: IR pre-drying to increase production capacity
- Double-roller steering: Stronger transport for heavy belts
- Electric or gas heating: Selectable heating type
| Technical Specifications | Details |
|---|---|
| Cylinder Width | 300 mm |
| Hot Air Dryer Contents | 50 m |
| 10 mm Tape Capacity | 12 pieces |
| 25 mm Tape Capacity | 8 pieces |
| Connected / Active Power | 35 / 23 kW |
| Air Consumption | 6 bar |
| Drying Temperature | Maximum 210°C |
| Working Speed | 30 m/min |
| Machine Dimensions (LxWxH) | 340 × 50 × 210 cm |
| Heating Type | Electric or gas (optional) |
| Certification | CE Compliant |
Dar dokuma makineleri, kroşe örme makineleri, çözgü makineleri, rulo sarım makineleri ve medikal tekstil üretim ekipmanları dahil olmak üzere geniş bir tekstil makine yelpazesi üretiyoruz.
Evet, müşterilerimizin makinelerini verimli ve sorunsuz kullanabilmesi için kurulum hizmeti, operatör eğitimi ve sürekli teknik destek sağlıyoruz.
Makinelerimiz üretim gereksinimlerine göre özelleştirilebilir. Müşteri ihtiyaçlarına bağlı olarak en, hız, elektronik kontrol sistemleri ve opsiyonel özelliklerde esneklik sunuyoruz.
Makinelerimiz polyester, naylon, pamuk, elastik iplikler ve özel medikal tekstiller gibi çeşitli malzemelerin işlenmesi için tasarlanmıştır. Genellikle giyim, teknik tekstiller, medikal ürünler ve endüstriyel uygulamalarda kullanılır.
Web sitemizdeki iletişim formu, e-posta veya telefon aracılığıyla satış ekibimizle iletişime geçebilirsiniz. Üretim bilgileriniz bize ulaştığında, size özel bir fiyat teklifi hazırlayacağız.
We manufacture a wide range of textile machinery including narrow fabric weaving machines, crochet knitting machines, warping machines, roll winding machines, and medical textile production equipment.
Yes, we offer complete installation services, operator training, and ongoing technical support to ensure that our customers use their machines efficiently and without interruption.
Our machines can be customized according to production requirements. We offer flexibility in widths, speeds, electronic control systems, and additional optional features depending on customer needs.
Our machines are designed to process a variety of materials such as polyester, nylon, cotton, elastic yarns, and specialized medical textiles. They are commonly used in apparel, technical textiles, medical products, and industrial applications.
You can contact our sales team through email, phone, or the contact form on our website. Once we receive your production details, we will prepare a customized quotation for you.
