C450 Multi-Purpose Warping Machine
It is used in preparing warp on bobbins and beams for light elastic and non-elastic yarns.
Our C450 warping machine is suitable for the properties of light elastic and non-elastic yarns.
Machine Concept
Constant yarn tension is maintained from the core of the warp beam to the final yarn layer. This machine is highly suitable for fine and medium-weight yarns up to a maximum of 3000 dtex. The minimum yarn count for approximately 100 dtex is 25 threads.
Control and Drive System
The use of the machine control system, which now makes it even easier to program and record process parameters for reuse, means that integrating additional hardware into the machine no longer poses a problem. In line with our customers’ needs, these machines are manufactured with a frequency-controlled three-phase drive system. From the control panel, it is possible to adjust the unwinding and winding speeds, as well as the length to be wound.
- Adjustable meter counter and automatic stop.
- Semi-automatic reel loading and unloading system.
- Automatic stop in case of rope breakage.
- Comb with adjustable sliding system.
- Electromagnetic braking system.
- High speed and easy warp adjustment.
- Working with all kinds of yarn.
- A special clamp for the thread to be wound.
- Precise measurement.
- Safety system equipped with a safety switch.
| Roller Width | Min. 20 cm, Max. 40 cm |
|---|---|
| Roller Diameter | Standard 35 cm – Max. 50 cm |
| Speed | 1,500 RPM/min (adjustable) |
| Yarn Types | Polypropylene, Polyester, Cotton, Monofilament, etc. |
| Electric | 1.5 kW Brake Motor, 380V, 3Ph |
| Dimensions | 120 cm Width – 200 cm Length + Legs |
| Equipment | Calling |
Dar dokuma makineleri, kroşe örme makineleri, çözgü makineleri, rulo sarım makineleri ve medikal tekstil üretim ekipmanları dahil olmak üzere geniş bir tekstil makine yelpazesi üretiyoruz.
Evet, müşterilerimizin makinelerini verimli ve sorunsuz kullanabilmesi için kurulum hizmeti, operatör eğitimi ve sürekli teknik destek sağlıyoruz.
Makinelerimiz üretim gereksinimlerine göre özelleştirilebilir. Müşteri ihtiyaçlarına bağlı olarak en, hız, elektronik kontrol sistemleri ve opsiyonel özelliklerde esneklik sunuyoruz.
Makinelerimiz polyester, naylon, pamuk, elastik iplikler ve özel medikal tekstiller gibi çeşitli malzemelerin işlenmesi için tasarlanmıştır. Genellikle giyim, teknik tekstiller, medikal ürünler ve endüstriyel uygulamalarda kullanılır.
Web sitemizdeki iletişim formu, e-posta veya telefon aracılığıyla satış ekibimizle iletişime geçebilirsiniz. Üretim bilgileriniz bize ulaştığında, size özel bir fiyat teklifi hazırlayacağız.
We manufacture a wide range of textile machinery including narrow fabric weaving machines, crochet knitting machines, warping machines, roll winding machines, and medical textile production equipment.
Yes, we offer complete installation services, operator training, and ongoing technical support to ensure that our customers use their machines efficiently and without interruption.
Our machines can be customized according to production requirements. We offer flexibility in widths, speeds, electronic control systems, and additional optional features depending on customer needs.
Our machines are designed to process a variety of materials such as polyester, nylon, cotton, elastic yarns, and specialized medical textiles. They are commonly used in apparel, technical textiles, medical products, and industrial applications.
You can contact our sales team through email, phone, or the contact form on our website. Once we receive your production details, we will prepare a customized quotation for you.
